Widely used custom design disposable plastic cup making machine

Name: Widely used custom design disposable plastic cup making machine
Brand: HUALDA
Price: 1 USD

Quality Widely used custom design disposable plastic cup making machine for sale

Processing Type : Plastic Thermoforming Machine

Condition : New

Product Type : Plastic Cup

Place of Origin : Zhejiang, China (Mainland)

Brand Name : HUALDA

Model Number : HLD-660H

Voltage : 380V

Power(W) : 67kw

Dimension(L*W*H) : 3500*1800*2500mm

Weight : 4.8t

Certification : CE

Warranty : 1 Year

After-sales Service Provided : Engineers available to service machinery overseas

Forming Width : 400-630mm

Forming Thickness : 0.25-2.5mm

Stretching Length : 160mm

Max.height of cup : 125mm

Max. Fitting Area : 620X300mm

Sheet Feeding by servo Motor : 2.2KW

Oil Pump Motor : 7.5kw

Heating System : 55kW

Price : Negotiable

MOQ : 1 Set/Sets

Contact Now

Widely used custom design disposable plastic cup making machine

1:Functions:
1).Making round cups, and which can works all by itself. it combines the material feeding heating

forming blowing cutting transporting into one process.

2).Making square cups and other shape cups which can be cutting with page. It combines the material

feeding, heating blowing page cutting and transporting into one process.

2:Remark:

1).this machine adopts servo motor feeding

2).PLC control perform component

3).Sheet heating, hydraulic increase the speed, mechanism mould locking,stretch,cut ,huff forming,

products delivery auto-complete.

4).Heating is controlled by temperature controller,it divide into up 8 heating area ,and down 8 heating area .

Main Equipment:

Model		HLD-660H(two pillar)
Forming Width		400-630mm
Forming Thickness		0.25-2.5mm
Stretching Length		160mm
Max.height of cup		125mm(if the height more than 125mm pls choose another model machine
Route Length Adjust		100-400mm
Max. Fitting Area		620X300mm²
Electricity Consumption	Sheet Feeding by servo Motor	2.2KW
	Oil Pump Motor	7.5kw
	Heating System	55kW
Heating System		650w white heating Brick 104 pcs
Temp. Control		16 Groups Temp. Control and PLC
